| 技术参数Technical Parameter | |
| 额定载荷Rated Load | 50-75klb |
| 额定输出Rated Output | 1.9000±0.002MV/V |
| 综合误差Total Error | ±0.02%F.S |
| 蠕变Creep(30minutes) | ±0.02%F.S |
| 推荐工作电压Recommended Excitation Voltage | 5V～18V(AC or DC) |
| 最大工作电压Maximum Excitation Voltage | 24V(AC or DC) |
| 零点平衡Zero Balance | ±1%F.S |
| 输入阻抗Input Impedance | 775±10Ω |
| 输出阻抗Output Impedance | 700±5Ω |
| 绝缘阻抗Insulation Impedance | ≥5000MΩ |
| 安全过载率Safe Overload | 150%F.S |
| 极限过载率Ultimate Overload | 200%F.S |
| 工作温度范围Operating Temperature Range | (-30～+70)℃ |
| 温度补偿范围Compensated Temperature Range | (-20～+60)℃ |
| 输出温度影响Temperature Effect On Load | ±0.02%F.S/10℃ |
| 零点温度影响Temperature Effect On Zero | ±0.02%F.S/10℃ |
| 材质Construction | 合金钢Alloy Steel |
| 防护等级Protection Class | IP68&IP67 |
| 引用标准Citation | GB/T7551-2008/OIML R60 |
| 接线方式Mode of Connection |
输入+E:红 Input+ E:Red 输出-S:白 Output- S:White 输入-E:黑 Input- E:Black 输出+S:绿 Output+ S:Green |
